The ZF Gearbox fitted to the majority of BMW's and the software that is used can be somewhat frustrating to BMW owners across the globe. Here at Turner's we offer BMW Gearbox Remapping for a vast range of ZF Gearboxes (6HP Gearbox variants and 8HP Gearbox variants) providing dramatic improvements in behavior and performance. To provide this service, we work with XHP Flashtool who are known worldwide in being the best for BMW gearbox Remaps.
WHAT IMPROVEMENTS WILL I GET FROM THE GEARBOX REMAP?
This is one of the most common questions we get asked regarding Remapping of these ZF boxes. There are major calibrations carried out to the stock TCU (Transmission Control Unit) software providing great additional benefits to the somewhat simplified factory software. A XHP Flashtool Gearbox Remap boasts many advantages which, including but not limited too, we will list below;
- Kickdown delete
- Raised Torque Limiters (Compliments vehicles even more so that have had an Engine ECU Remap)
- Modified shift points
- Reduced shift time
- Gear Display in Dash in D/S/M Modes on most models
- Calibrated Shift Strategy for up/downhill driving
- Optimized Warmup Behaviour
- Launch control (Available for some of the later 8HP Gearboxes)
Typical Stage Modifications
Stage 1
- Optimized D Shiftpoints to facilitate sporty, yet economy style driving
- Optimized Shift Strategy for up/downhill driving
- Optimized Warmup Behaviour
- Optimized Torque Converter Lockup in 1st/2nd/3rd gear
- Lowered minimum RPM limit manual mode
- Adapted Torque Limits for Tuned engines
- Kickdown delete in Manual Mode
- Gear Display in Dash in D/S/M Modes
Stage 2
- Optimized D & S Shiftpoints for better acceleration in part and full throttle situations
- Firmer, sportier upshifts in D/S/M mode
- Faster paddle response time
- Optimized Shift Strategy for up/downhill driving
- Optimized Warmup Behaviour
- Optimized Torque Converter Lockup in 1st/2nd/3rd gear
- Raised Torque Limits for Tuned engines
- Kickdown delete in Manual Mode
- Gear Display in Dash in D/S/M Modes
Stage 3
- Optimized D & S Shiftpoints for better acceleration in part and full throttle situations
- Race-like upshifts with TQ increase
- Shift times approx. 50% faster in S/M Modes
- Shift times approx. 25% faster in D Mode
- True Manual mode (no automatic upshift in M mode)
- Automatic Rev-Matching (Throttle – Blip) on Downshifts in S/M Modes
- Faster paddle response time
- Optimized Shift Strategy for up/downhill driving
- Optimized Warmup behavior
- Optimized Torque Converter Lockup in 1st/2nd/3rd gear
- Even more raised Torque Limits for Tuned engines
- Kickdown delete in Manual Mode
- Gear Display in Dash in D/S/M Modes
These are just some of the features that improve your BMW Gearbox. There are 3 different Stages of an XHP Flashtool Remap depending on you and your vehicle. Stage 1 is for vehicles and drivers who are set up for the more fuel economic way of driving but still enjoy some spirited driving when the need and desire takes. Stage 2 and 3 are for the performance lovers out there who are focused on gaining the most they can from both the Engine and Transmission.
Want to benefit from an XHP Flashtool Remap for your BMW? As long as you have your chassis number handy you can check your vehicles compatibility using the SELECTOR - You can then get in touch with one of the team who can provide a quotation and discuss availability. Dont have your chassis number to hand? No problems at all, Contact Us today and one of our team will do all the hard work for you!
Cant decide which Stage meets your requirements
We are happy to change the Stage of tune installed on your car, in the first 14 days this is completely free of charge for up to 2 changes, this means that you can change your mind and go from one Stage to another as you like.
Custom xHP Gearbox Tuning
In addition to the standard, Stage 1, Stage 2 and Stage 3 xHP gearbox tunes above we also offer the above xHP Gearbox Remaps with Customisation, we are able to modify the gearbox tunes to meet whatever you would like. So for example you can go from Stage 1, to a Stage 1 with Increased (up to 50%) Shift Times, the options and changes are almost unlimited.
